PROCESSOR INTEL 10TH GEN CORE I5-10500T

CPU Specifications

• Total Cores 6

• Total Threads 12

• Max Turbo Frequency 3.80 GHz

• Intel® Turbo Boost Technology 2.0 Frequency‡ 3.80 GHz

• Processor Base Frequency 2.30 GHz

• Cache 12 MB Intel® Smart Cache

• Bus Speed 8 GT/s

• TDP 35 W

• Configurable TDP-down Base Frequency 1.70 GHz

• Configurable TDP-down 25 W


Supplemental Information

• Marketing Status Launched

• Launch Date Q2'20

• Embedded Options Available No

• Use Conditions PC/Client/Tablet

• Datasheet View now


Memory Specifications

• Max Memory Size (dependent on memory type) 128 GB

• Memory Types DDR4-2666

• Max # of Memory Channels 2

• Max Memory Bandwidth 41.6 GB/s

• ECC Memory Supported ‡ No


GPU Specifications

• GPU Name‡ Intel® UHD Graphics 630

• Graphics Base Frequency 350 MHz

• Graphics Max Dynamic Frequency 1.15 GHz

• Graphics Video Max Memory 64 GB

• 4K Support Yes, at 60Hz

• Max Resolution (HDMI)‡ 4096 x 2160@30Hz

• Max Resolution (DP)‡ 4096 x 2304@60Hz

• Max Resolution (eDP - Integrated Flat Panel)‡ 4096 x 2304@60Hz

• DirectX* Support 12

• OpenGL* Support 4.5

• Intel® Quick Sync Video Yes

• Intel® InTru™ 3D Technology Yes

• Intel® Clear Video HD Technology Yes

• Intel® Clear Video Technology Yes

• # of Displays Supported ‡ 3

• Device ID 0x9BC8


Expansion Options

• Scalability 1S Only

• PCI Express Revision 3.0

• PCI Express Configurations ‡ Up to 1x16, 2x8, 1x8+2x4

• Max # of PCI Express Lanes 16


Package Specifications

• Sockets Supported FCLGA1200

• Max CPU Configuration 1

• Thermal Solution Specification PCG 2015B

• TJUNCTION 100°C

• Package Size 37.5mm x 37.5mm


Advanced Technologies

• Intel® Optane™ Memory Supported ‡ Yes

• Intel® Thermal Velocity Boost No

• Intel® Turbo Boost Max Technology 3.0 ‡ No

• Intel® Turbo Boost Technology ‡ 2.0

• Intel® Hyper-Threading Technology ‡ Yes

• Intel® Transactional Synchronization Extensions No

• Intel® 64 ‡ Yes

• Instruction Set 64-bit

• Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

• Idle States Yes

• Enhanced Intel SpeedStep® Technology Yes

• Thermal Monitoring Technologies Yes

• Intel® Identity Protection Technology ‡ Yes


Security & Reliability

• Intel vPro® Eligibility ‡ Intel vPro® Platform

• Intel® Software Guard Extensions (Intel® SGX) Yes with Intel® ME

• Intel® AES New Instructions Yes

• Secure Key Yes

• Intel® OS Guard Yes

• Intel® Trusted Execution Technology ‡ Yes

• Execute Disable Bit ‡ Yes

• Intel® Boot Guard Yes

• Intel® Stable IT Platform Program (SIPP) Yes

• Intel® Virtualization Technology (VT-x) ‡ Yes

• Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes

• Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
